7-4 FlexPak 3000 DC Drive Software Reference
Table 7.1 – Options for Metering Parameters
Signal Selected Full Scale Value
CML FEEDBACK (P.397)
CML REFERENCE (P.396)
CML ERROR (P.398)
SPD LOOP OUTPUT (P.299)
(amps)
or
MAXIMUM CURRENT (% full load amps)
SPD LOOP FEEDBACK (P.296)
SPD LOOP REFERENCE (P.295)
SPD LOOP ERROR (P.297)
SPEED RAMP OUTPUT (P.199)
SPEED RAMP INPUT TP (P.198)
SPD SOURCE SELECT OUT (P.193)
TRIM OUTPUT (P.197)
ANALOG TACH FEEDBACK (P.291)
PULSE TACH FEEDBACK (P.292)
OCL OUTPUT (P.848)
TOP SPEED ( RPM )
ARMATURE VOLTAGE (P.289) MOTOR RATED ARM VOLTS (volts)
POWER OUTPUT
watts
FIELD REFERENCE (P.590)
FIELD FEEDBACK (P.589)
MOTOR HOT FLD AMPS (amps)
OCL REFERENCE (P.845)
OCL RAMP OUTPUT (P.846)
OCL FEEDBACK (P.847)
NETW IN REG 1 (P.905)
NETW IN REG 2 (P.906)
NETW IN REG 3 (P.907)
FULL SCALE
4095 (counts)
ZERO 0
MOTOR RATED ARM AMPS
MAXIMUM CURRENT
100
------------------------------------------------------------
×
MOTOR RATED ARM VOLTS MOTOR RATED ARM AMPS ×
MAXIMUM CURRENT
100
