Page 42: P.122)
4-22
FlexPak 3000 DC Drive Software Reference
SPD
SOURCE
SELECT
OUT
(P.193)
The selected speed
reference source
value in
RPM
or the
units you defined. It is
an input to the speed
reference ramp
section.
Parameter Range:
n/a
Default Setting:
n/a
Parameter Type:
Output
OIM Menu Path(s):
Drive Reference - Drive Reference Test Points
SPEED
RAMP
INPUT
TP
(P.198)
The value of the
speed reference
signal immediately
before the speed loop
S-curve block.
Parameter Range:
n/a
Default Setting:
n/a
Parameter Type:
Output
OIM Menu Path(s):
Drive Reference – Drive Reference Test Points
SPEED
RAMP
OUTPUT
(P.199)
The value of the
speed reference
signal immediately
after the speed loop
S-curve block.
Parameter Range:
n/a
Default Setting:
n/a
Parameter Type:
Output
OIM Menu Path(s):
Drive Reference – Drive Reference Test Points
STOP
DECEL
SELECT
(P.122)
Selects which
deceleration time will
be used for ramp stop
sequences,
DECELERATION
TIME
(P.002) or
RAMP
STOP
DECEL
TIME
(P.018).
Parameter Range:
1 =
DECELERATION
TIME
2 =
RAMP
STOP
DECEL
TIME
Default Setting:
1
Parameter Type:
Configurable
OIM Menu Path(s):
Additional Parameters (listed by parameter number)
This only affects ramp stop times. Speed changes when the drive is running use
DECELERATION
TIME
regardless of the
STOP
DECEL
SELECT
choice.
