C-5
DIG OUT 2 CONTACT TYP (P.412) • NORMAL OPEN
• NORMAL CLOSED
NORMAL OPEN
DIG OUT 2 SELECT (P.411) • LEVEL DETECT 1 OUTPUT
• LEVEL DETECT 2 OUTPUT
• IN CURRENT LIMIT
• DRIVE READY
• NETW COMM STATUS
• NETW IN REG 1 ( BIT 1)
• NETW IN REG 2 ( BIT 1)
• NETW IN REG 3 ( BIT 1)
LEVEL DETECT 2
OUTPUT
ENHANCED FLD VOLT ADJ (P.500) • 0 to 180 (J21 set to B-C)
• 0 to 120 (J21 set to A-C)
84
0 when the Field
Current
Regulator kit is
installed
FEEDBACK SELECT (P.200) • ARMATURE VOLT
• DC TACH
• PULSE TACH
• AC TACH
ARMATURE VOLT
FIELD AUTO WEAKEN (P.517) • DISABLED
• ENABLED
DISABLED
FIELD DELTA HIGH LIM (P.587) 0 to 180 DEGREE 130 DEGREE
FIELD ECONOMY DELAY (P.501) 0 to 27 minutes 5 minutes
FIELD ECONOMY REF (P.511) 0 to 100% 0%
FIELD LOSS THRESHOLD (P.512) • 50 to 100% of MOTOR HOT FLD
AMPS (P.510) when FEEDBACK
SELECT (P.200) is set to ARMATURE
VOLT
• 0 to 100% of MOTOR HOT FLD AMPS
(P.510) when FEEDBACK SELECT
(P.200) is set to DC TACH , PULSE
TACH , or AC TACH
60% of MOTOR
HOT FLD AMPS
(P.510)
FIELD PI LEAD FREQ (P.515) 0 to 282.70 RAD / S 1.50 RAD / S
FIELD PI PROP GAIN (P.514) 0.10 to 128.00 0.50
FIELD REF REGISTER (P.513) 0 to MOTOR HOT FLD AMPS MOTOR HOT FLD
AMPS
Table C.1 – Parameter Settings Quick Reference Table (Continued)
Parameter
Parameter Selection/
Adjustment Range
Initial Factory
Setting (Default)
Your Data
Date Setting
