C-14 FlexPak 3000 DC Drive Software Reference
SPD LOOP PI RESET • 0 = OFF
• 1 = ON
0
SPD LOOP SCAN TIME • 5 msec
• 10 msec
5 msec
SPEED FEEDBACK GAIN 1000 to 32000 1000
STOP DECEL SELECT (P.122) • 1 = DECELERATION TIME
• 2 = RAMP STOP DECEL TIME
1
STOP MODE SELECT (P.114) • RAMP
• COAST / DB
• CURRENT LIMIT
COAST / DB
STOP SPEED THRESHOLD (P.113) 0 to MAXIMUM SPEED ( RPM or user-
defined units
50 RPM
TACH LEAD FLT DELAY (P.228) 0 to 32767 msec 10000 msec
TACH LEAD FLT THRESH (P.227) 0.0 to 250.0% of TOP SPEED 200.0%
TACH LOSS SCR ANGLE (P.608) 0 to 127 DEGREE 109 DEGREE
TOP SPEED (P.011) 5 to 5000 RPM 500 RPM
TRIM MODE SELECT (P.110) • NO TRIM
• INCREMENTAL
• PROPORTIONAL
NO TRIM
TRIM RANGE (P.109) 0.0 to 100.0% 0.0%
TRIM REFERENCE SELECT (P.108) • ANALOG MANUAL
• REGISTER
• ANALOG IN 1
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
• ANALOG IN 2
REGISTER
TRIM REF REGISTER (P.107) ±100.0% 0%
UNDERWIND ENABLE 0 = DISABLED (overwind)
1 = ENABLED (underwind)
0
Table C.1 – Parameter Settings Quick Reference Table (Continued)
Parameter
Parameter Selection/
Adjustment Range
Initial Factory
Setting (Default)
Your Data
Date Setting
