C-10
FlexPak 3000 DC Drive Software Reference
NEG
CURRENT
LIM
SEL
(P.224)
•
REGISTER
•
ANALOG
IN
1
•
ANALOG
IN
2
•
NETW
IN
REG
1
•
NETW
IN
REG
2
•
NETW
IN
REG
3
REGISTER
NEGATIVE
CURRENT
LIM
(P.006)
When
NEG
CUR
LIM
INV
EN
(P.226) =
ENABLED
: 0
to
MAXIMUM
CURRENT
(%
FLA
)
When
NEG
CUR
LIM
INV
EN
(P.226) =
DISABLED
: –
MAXIMUM
CURRENT
to
0 (%
FLA
)
±150 %
FLA
NEG
CUR
LIM
INV
EN
(P.226)
•
DISABLED
•
ENABLED
ENABLED
NETW
COMM
LOSS
SELECT
(P.901) •
FAULT
•
USE
LAST
REF
•
USE
TRMBLK
REF
•
USE
TRMBLK
CNTL
FAULT
NETW
CONNECT
TYPE
(P.910)
•
BASIC
•
FULL
BASIC
NETW
DROP
NUMBER
(P.900)
For AutoMax Network
Communication kit: 1 to 55 if
NETW
CONNECT
TYPE
=
BASIC
; 1 to 52 if
NETW
CONNECT
TYPE
=
FULL
For DeviceNet Interface kit: 0 to 63
(
NETW
CONNECT
TYPE
value does
not affect)
For ControlNet Network
Communication kit: 1 to 99
(
NETW
CONNECT
TYPE
value does not
affect)
1
NETW
OUT
REG
1
SELECT
(P.902)
–32768 to 32767
0
NETW
OUT
REG
2
SELECT
(P.903)
–32768 to 32767
0
NETW
OUT
REG
3
SELECT
(P.904)
–32768 to 32767
0
NETW
REGISTER
MAP
SEL
(P.914)
• 1 =
ORIGINAL
• 2 =
ALTERNATE
1
NETWORK
BAUD
RATE
(P.912)
• 0.0 Kbaud
• 125.0 Kbaud
• 250.0 Kbaud
• 500.0 Kbaud
0.0 Kbaud
Table C.1 – Parameter Settings Quick Reference Table (Continued)
Parameter
Parameter Selection/
Adjustment Range
Initial Factory
Setting (Default)
Your Data
Date
Setting
