Rockwell Automation FlexPak 3000 Digital DC Drive Version 4.3 User Manual
Page 2
©2001 Rockwell Automation. All rights reserved.
The information in this manual is subject to change without notice.
Throughout this manual, the following notes are used to alert you to safety considerations:
Important: Identifies information that is critical for successful application and understanding of the product.
The thick black bar shown on the outside margin of this page will be used throughout this instruction manual to
signify new or revised text or figures.
!
ATTENTION: Identifies information about practices or circumstances that can lead to personal
injury or death, property damage, or economic loss.
Reliance, FlexPak, AutoMax, and E.S.P. are trademarks of Rockwell Automation.
DeviceNet is a trademark of the Open DeviceNet Vendor Association.
!
ATTENTION: Only qualified electrical personnel familiar with the construction and operation of
this equipment and the hazards involved should install, operate, or service this equipment. Read
and understand this manual in its entirety before proceeding. Failure to observe this precaution
could result in severe bodily injury or loss of life.
