C-1
A
PPENDIX
C
Parameter Settings Record
This table provides space for you to record input parameter settings for reference.
Table C.1 – Parameter Settings Quick Reference Table
Parameter
Parameter Selection/
Adjustment Range
Initial Factory
Setting (Default)
Your Data
Date Setting
ACCELERATION TIME (P.001) 0.1 to 300.0 seconds 5.0 seconds
AMX NETW REF SELECT (P.911) • DIRECT
• BROADCAST n (n=1 to 8)
DIRECT
ANALOG TACH GAIN ADJ (P.201) 0.750 to 1.250 1.000
ANALOG TACH ZERO ADJ (P.202) –200 to 200 0
ANLG AUTO GAIN ADJ (P.101) 0.750 to 1.250 1.000
ANLG AUTO SIGNAL TYPE (P.100) • 0– 10V
• +/–10 V
• 4-20 mA
• 10 -50mA
0– 10V
ANLG AUTO ZERO ADJ (P.102) –200 to 200 0
ANLG IN 1 GAIN ADJ (P.415) 0.750 to 2.250 1.000
ANLG IN 1 SIG TYPE (P.413) • 0– 10 V
• +/–10 V
• 4-20 mA
• 10-50 mA
+/–10 V
ANLG IN 1 ZERO ADJ (P.414) –200 to 200 0
ANLG IN 2 GAIN ADJ (P.417) 0.750 to 2.250 1.000
ANLG IN 2 ZERO ADJ (P.416) –200 to 200 0
ANLG MAN REF GAIN ADJ (P.104) 0.750 to 1.250 1.000
ANLG MAN REF ZERO ADJ (P.105) –200 to 200 0
ANLG OUT 1 GAIN ADJ (P.420) 0.500 to 1.300 1.000
