INERTIA COMP SELECT (P.221) • NONE
• INTERNAL
• ANALOG IN 1
• ANALOG IN 2
• NETW IN REG 1
• NETW IN REG 2
• NETW IN REG 3
NONE
INV FAULT AVOID SEL (P.312) • 1 = DISABLED
• 2 = FAULT IMMEDIATELY
• 3 = DELAY BEFORE FAULT
DISABLED
IR COMPENSATION (P.206) 0 to 50% 0%
JOG ACCEL / DECEL TIME (P.013) 0.1 to 300.0 seconds 3.0 seconds
JOG OFF DELAY TIME (P.121) 0.0 to 10.0 seconds 1.0 second
JOG SPEED 1 (P.012) 0 to MAXIMUM SPEED ( RPM or user-
defined units)
250 RPM
JOG SPEED 2 (P.017) 0 to MAXIMUM SPEED ( RPM or user-
defined units)
250 RPM
LEVEL DETECT 1 DELAY (P.604) 0.0 to 300.0 seconds 10.0 seconds
LEVEL DETECT 1 SELECT (P.602) • CML FEEDBACK
• SPD LOOP FEEDBACK
• SPD RAMP INPUT TP
• SPEED RAMP OUTPUT
• SPD SOURCE SELECT OUT
SPD LOOP
FEEDBACK
LEVEL DETECT 1 THRESH (P.603) 0.1 to 100.0% or MAXIMUM CURRENT 10.0%
LEVEL DETECT 2 DELAY (P.607) 0.0 to 300.0 seconds 10.0 seconds
LEVEL DETECT 2 SELECT (P.605) • CML FEEDBACK
• SPD LOOP FEEDBACK
• SPD RAMP INPUT TP
• SPEED RAMP OUTPUT
• SPD SOURCE SELECT OUT
SPD RAMP INPUT
TP
LEVEL DETECT 2 THRESH (P.606) 0.1 to 100.0% or MAXIMUM CURRENT 10.0%
MANUAL REF SELECT (P.106) • ANALOG
• MOP
ANALOG
MAXIMUM CURRENT (P.007) 25 to 200 % FLA 150 % FLA
Table C.1 – Parameter Settings Quick Reference Table (Continued)
Parameter
Parameter Selection/
Adjustment Range
Initial Factory
Setting (Default)
Your Data
Date Setting
