Configuring the Drive to Use Level Detectors
12-3
LEVEL
DETECT
2
DELAY
(P.607)
The delay time in
seconds for the level
detector 2 circuit.
Parameter Range:
0.0 to 300.0 seconds
Default Setting:
10.0 seconds
Parameter Type:
Tunable
OIM Menu Path(s):
Input/Output - Level Detectors
Sets the amount of time between when the level detector timer is triggered and
when the output is set
ON
. If the input source signal goes below the detector’s
threshold value, the timer is immediately reset.
LEVEL
DETECT
2
OUTPUT
(P.649)
The output of level
detector 2. This
signal drives digital
output 2 (terminals
68 and 69 on the I/O
Expansion kit) if
DIG
OUT
2
SELECT
is set to
LEVEL
DETECT
2
OUTPUT
.
Parameter Range:
ON
OFF
Default Setting:
n/a
Parameter Type:
Output
OIM Menu Path(s):
Input/Output - Level Detectors
ON
when the input signal selected by
LEVEL
DETECT
2
SELECT
(P.605) is greater than
or equal to
LEVEL
DETECT
2
THRESH
(P.606) for longer than
LEVEL
DETECT
2
DELAY
(P.607).
OFF
whenever the input signal is less than
LEVEL
DETECT
2
THRESH
.
LEVEL
DETECT
2
SELECT
(P.605)
Selects the signal
that drives level
detector 2.
Parameter Range:
CML
FEEDBACK
SPD
LOOP
FEEDBACK
SPD
RAMP
INPUT
TP
SPEED
RAMP
OUTPUT
SPD
SOURCE
SELECT
OUT
Default Setting:
SPD
RAMP
INPUT
TP
Parameter Type:
Configurable
OIM Menu Path(s):
Input/Output - Level Detectors
