Rockwell Automation FlexPak 3000 Digital DC Drive Version 4.3 - Manual (Page 180)

D-2 FlexPak 3000 DC Drive Software Reference
196 DRAW PERCENTAGE OUT 4-14
197 TRIM OUTPUT 4-15
198 SPEED RAMP INPUT TP 4-22
199 SPEED RAMP OUTPUT 4-22
200 FEEDBACK SELECT 5-3
201 ANALOG TACH GAIN ADJ 5-7
202 ANALOG TACH ZERO ADJ 5-7
203 ANLG TACH VOLTS /1000 5-7
204 ARM VOLTAGE GAIN ADJ 5-4
205 ARM VOLTAGE ZERO ADJ 5-4
206 IR COMPENSATION 5-5
207 PULSE TACH PPR 5-9
208 PULSE TACH QUADRATURE 5-10
209 CURRENT COMPOUNDING 4-28
211 SPD LOOP PI PROP GAIN 5-19
212 SPD LOOP PI LEAD FREQ 5-19
213 SPD LEADLAG RATIO 5-12
214 SPD LEADLAG LOW FREQ 5-11
215 SPD LOOP LAG FREQ 5-13
216 SPD LEADLAG SELECT 5-12
217 SPD LOOP LAG BYPASS 5-13
218 SELF TUNE FIELD RANGE 3-3
219 SELF TUNE STABILITY 3-4
220 SELF TUNE BRIDGE 3-3
221 INERTIA COMP SELECT 6-2
222 NORMALIZED INERTIA 6-3
223 POS CURRENT LIM SEL 5-16
224 NEG CURRENT LIM SEL 5-15
226 NEG CUR LIM INV EN 5-15, 6-4
227 TACH LEAD FLT THRESH 13-19
228 TACH LEAD FLT DELAY 13-19
Table D.1 – Numeric List of Parameters (Continued)
Number Name Page
289 ARMATURE VOLTAGE 5-4
290 IR COMPENSATION TP 5-5
291 ANALOG TACH FEEDBACK 5-6
292 PULSE TACH FEEDBACK 5-9
293 CURRENT COMPOUND TP 4-28
294 JOG RAMP OUTPUT 4-27
295 SPD LOOP REFERENCE 4-24
296 SPD LOOP FEEDBACK 5-12
297 SPD LOOP ERROR 5-12
298 SPD LOOP LAG OUTPUT 5-13
299 SPD LOOP OUTPUT 5-18
300 CML FEEDBACK GAIN ADJ 6-7
301 CML PI PROP GAIN 6-10
302 CML PI LEAD FREQUENCY 6-10
303 CML REF RATE LIMIT 6-4
306 NOMINAL AC LINE FREQ 3-2
307 NOMINAL AC LINE VOLTS 3-2
308 PLL MAXIMUM ERROR 13-13
309 PHASE FIRE TEST DELTA 13-18
310 PHASE FIRE TST BRIDGE 13-18
311 CML REF LIMIT SELECT 6-3
312 INV FAULT AVOID SEL 13-20
392 AC LINE VOLTAGE 13-22
393 AC LINE PERIOD 13-22
394 ARMATURE BRIDGE POL 6-9
395 J 18 ARM I FB RESISTOR 6-7
396 CML REFERENCE 6-4
397 CML FEEDBACK 6-7
398 CML ERROR 6-10
399 ARMATURE DELTA 6-10
400 METER OUT 1 GAIN ADJ 7-2
Table D.1 – Numeric List of Parameters (Continued)
Number Name Page
