12-2 FlexPak 3000 DC Drive Software Reference
LEVEL DETECT
1
OUTPUT
(P.648)
The output of level
detector 1. This
signal drives digital
output 1 (terminals
66 and 67 on the I/O
Expansion kit) if
DIG
OUT 1 SELECT is set to
LEVEL DETECT 1
OUTPUT .
Parameter Range: ON
OFF
Default Setting: n/a
Parameter Type: Output
OIM Menu Path(s): Input/Output - Level Detectors
ON when the input signal selected by LEVEL DETECT 1 SELECT (P.602) is greater than
or equal to LEVEL DETECT 1 THRESH (P.603) for longer than LEVEL DETECT 1 DELAY
(P.604).
OFF whenever the input signal is less than LEVEL DETECT 1 THRESH .
LEVEL DETECT 1 SELECT (P.602)
Selects the signal
that drives level
detector 1. Parameter Range: CML FEEDBACK
SPD LOOP FEEDBACK
SPD RAMP INPUT TP
SPEED RAMP OUTPUT
SPD SOURCE SELECT OUT
Default Setting: SPD LOOP FEEDBACK
Parameter Type: Configurable
OIM Menu Path(s): Input/Output - Level Detectors
LEVEL DETECT 1 THRESH (P.603)
The threshold for
level detector 1. Parameter Range:* 0.1 to 100.0% or MAXIMUM CURRENT
Default Setting: 10.0%
Parameter Type: Tunable
OIM Menu Path(s): Input/Output - Level Detectors
When the absolute value of the signal driving level detector 1 is greater than or
equal to this threshold, the associated timer starts. If the input signal is less than
this threshold, the timer is immediately reset. The level detector output is set to
OFF .
*The parameter range for the level detector is automatically rescaled for speed or
current based on the input selected by
LEVEL DETECT 1 SELECT (P.602). If CML
FEEDBACK is selected for LEVEL DETECT 1 SELECT , the parameter range is 0.1 to
MAXIMUM CURRENT . For any other LEVEL DETECT 1 SELECT settings, the parameter
range is 0.1 to 100.0%.
