4–13 Start–Up and Adjustment
Publication 1397-5.0 — June, 2001
Figure 4.8
DC Motor Field Connection Location
TOP VIEW
40 – 75HP at 230 VAC
265A @ 380/415 VAC
75 – 150 HP at 460 VAC
100 – 150 HP at 230 VAC
200 – 300 HP at 460 VAC
TOP VIEW
A1 A2/S1 DBR S2
400 – 600 HP at 460 VAC
1 2 3 4 F1 F2
DC Motor Field
Connection
1 2 3 4 F1 F2
DC Motor Field
Connection
DB Connections for
Option Kits
TOP VIEW
45
A1
