Rockwell Automation 1397 DC Drive Firmware 2.xx - Manual (Page 175)

5–65 Programming Parameters
Publication 1397-5.0 — June, 2001
DIAGNOSTICS
[Field Ref TP] — P.176
Field current reference testpoint. It is the
limited value of [Field Reference] or the field
economy reference — when [Field Econ
Active] is On. Refer to the Field Control
Loop (Dia A.10) block diagram for additional
information. Display/Drive Units: AMPS
Parameter Range: N/A
Group: Diagnostics
Factory Default: 0
Minimum Value: -0.1
Maximum Value: 15 Based on field regulator installed
[Field Regulator] — P.177
Indicates whether or not the Field Current
Regulator kit is installed. If it is installed, lists
the rating of the kit that is installed. Display/Drive Units: ENUM
Group: Diagnostics
Parameter Range: Not Installed
4 Amp
10 Amp
20 Amp
Factory Default: n/a
Minimum Value: Not Installed
Maximum Value: 20 Amp
[Expansion I/O] — P.178
Indicates whether or not the I/O Expansion kit
is installed in the drive and if it has passed
diagnostics. If the I/O Expansion Kit has
failed diagnostics, the drive is not operable
(the armature cannot become active). Display/Drive Units: Numeric/Text
Parameter Range: 0 = Not Installed
1 = Installed
2 = Failed Diags
3 = Failed Diags
Group: Diagnostics
Factory Default: 0 [Not Installed]
Minimum Value: 0 [Not Installed]
Maximum Value: 3 [Failed Diagnostics]
[IR Comp TP] — P.179
An output testpoint that represents the level
of [IR Comp] being used by the drive. This
parameter only has meaning if the selected
drive feedback is set to armature voltage. Display/Drive Units: VOLT
Group: Diagnostics
Type: Output
Factory Default: 0
Minimum Value: 0
Maximum Value: 338.0
