5–82
Programming Parameters
Publication 1397-5.0 — June, 2001
Process Display
[Process 1 Par] — P.247
This parameter should be set to the number
of the parameter whose scaled value will be
displayed on Line 1 of the HIM Display Panel.
Display/Drive Units:
Numeric/Text
Parameter Type:
Read & Write
Group:
Process Display
Minimum Value:
0
Factory Default:
5
Maximum Value:
308
[Process 1 Scale] — P.248
This value sets the scaling multiplier for
[Process 1 Par].
Display/Drive Units:
Numeric/Text
Parameter Type:
Read & Write
Group:
Process Display
Minimum Value:
–32768
Factory Default:
1.00
Maximum Value:
32767
[Process 1 Text 1] — P.249
Sets the “User Units” description for the value
determined by [Process 1 Par] and [Process
1 Scale]. The 8 character description will be
shown on line 1 of the display.
Display/Drive Units:
Numeric/Text
Parameter Range:
Alphanumeric
Parameter Type:
Read & Write
Group:
Process Display
Minimum Value:
32
Factory Default:
86
Maximum Value:
127
[Process 1 Text 2] — P.250
Sets the “User Units” description for the value
determined by [Process 1 Par] and [Process 1
Scale]. The 8 character description will be
shown on line 1 of the display.
Display/Drive Units:
Numeric/Text
Parameter Range:
Alphanumeric
Parameter Type:
Read & Write
Group:
Process Display
Minimum Value:
32
Factory Default:
111
Maximum Value:
127
