5–39 Programming Parameters
Publication 1397-5.0 — June, 2001
FEATURE SELECT
[Inertia Comp Src] — P.102
Sets the source of the inertia compensation
signal.
Internal uses [Normal Inertia] and [Maximum
Current] params to determine amount of
inertia compensation. Display/Drive Units: Numeric/Text
Parameter Range: 0 = NONE
1 = INTERNAL
2 = ANLG IN 3
3 = ANLG IN 4
4 = FREQUENCY IN
5 = ADAPTER 1
6 = ADAPTER 2
7 = ADAPTER 3
8 = ADAPTER 4
9 = ADAPTER 5
10 = ADAPTER 6
Group: Feature Select
Factory Default: 0
Minimum Value: 0
Maximum Value: 10
[Monitor 1 Delay] — P.103
The delay time in seconds for the level
detector 1 circuit. Sets the amount of time
between when the level detector timer is
triggered and when the output is set on. If the
input source signal goes below the detector’s
threshold value, the timer is immediately
reset. Refer to the Level Detectors block
diagram (Fig. A.12) for additional Information. Display/Drive Units: SECS
Default Setting: 10.0 seconds
Parameter Type: Tunable
Group: Feature Select
Factory Default: 1.0
Minimum Value: 0
Maximum Value: 300.0
