Recommended ac line and dc armature fuses – Rockwell Automation 1397 DC Drive Firmware 2.xx User Manual
Page 43

2–25
Installation
Publication 1397-5.0 — June, 2001
The following tables list the recommended AC line and DC armature
fuses for the Drive. The armature fuse is required only for
regenerative Drives.
Standard models are shipped with the appropriate fuses.
You must select the correct replacement fuse type from Tables 2.E
and 2.F.
Table 2.E
AC Line Fuses
AC Line Fuse (1FU, 2FU, 3FU)
HP at 230 V AC
HP at 380 V AC
HP at 415 V AC
HP at 460 V AC
Fuse Rating (500 V)
Fuse Class
Manufacturer
1.5-5
7.5-10
15
20-30
40-60
75
100
125-150
2.4
12
24
48
120
2.8
13.8
27.6
55.2
138
3-10
15-20
30
40-60
75-125
150
200
250-300
400-600
40A
80A
90A
150A
300A
350A
600A
800A
600A (700V)
2 in parallel
XL50F
XL50F
XL50F
XL50F
XL50F
XL50F
XL50F
XL50F
A70QS600–4K
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Gould
Table 2.F
DC Armature Fuses (Regenerative Drives Only)
DC Line Fuse (11FU)
HP at 230 V AC
A @ 380/415 V AC
HP at 460 V AC
Fuse Rating (700 V)
Fuse Class
Manufacturer
1.5
2
3
5
7.5
10
15
20-25
30
40
50
60
75
7
7
7
7
29
29
55
55
110
110
110
110
205
3
4
6
10
15
20
30
40-50
60
75
100
125
150
15A
20A
25A
35A
40A
50A
70A
125A
150A
200A
250A
300A
350A
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
XL70F
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Bussman
Recommended AC Line and
DC Armature Fuses
