Rockwell Automation 1397 DC Drive Firmware 2.xx User Manual
Page 268
Lifting Instructions
E–2
Publication 1397-5.0 — June, 2001
Figure E.2
Mounting Hole Pattern 60 HP Drives
Figure E.3
Mounting Hole Pattern 150 HP Drives
12.7 (0.50)
490.0 (19.29)
464.6 (18.29)
35.0 (1.38)
200.0 (7.87)
175.0 (6.89)
460.0 (18.11)
112.4 (4.43)
224.9 (8.86)
270.5 (10.65)
22.4 (0.88)
477.3 (18.79)
463.0 (18.23)
