Rockwell Automation 1397 DC Drive Firmware 2.xx User Manual

Page 66

3–8

Programming Terminal

Publication 1397-5.0 — June, 2001

Process Mode

and

1. When selected, the Process mode will show

a custom display consisting of information
programmed with the Process Display group
of parameters.

A. Follow steps A-C on the preceding page

to access the Program mode.

B. Press the Increment/Decrement key until

“Process Display” is shown. Press Enter.

C. Using the Increment/Decrement keys,

select [Process 1 Par] and enter the
number of the parameter you wish to
monitor. Press Enter.

D. Select [Process 1 Scale] using the

Increment/Decrement keys. Enter the
desired scaling factor. Press Enter.

E. Select [Process 1 Txt 1] using the

Increment/Decrement keys. Enter the
desired text character. Press Enter and
repeat for the remaining characters.

F. If desired, a second display line can also

be programmed by repeating steps A-E
for [Process 2 xxx] parameters.

G. When process programming is com-

plete, press ESCape until “Choose
Mode” is displayed. Press Increment/
Decrement until “Process” is displayed.

H. Press Enter. This selects which custom

display will be on line 1 and line 2. Use
the Increment/Decrement keys to select
process 1 or 2 parameters for line 1.

I. Press SELect to move to line 2. Select

the desired process parameters. A zero
can be entered to disable line 2. In
addition, the Process Display can be set
to appear when Drive power is applied
by simultaneously pressing the Incre-
ment and Decrement keys while the
Process Display active.

Choose Mode
Program

Choose Mode
Process

Process Var 1=1
Process Var 2=2

Choose Group
Process Display

Process 1 Par
5

Process 1 Scale
1.00

Process 1 Txt 1
V

Sets Process Display

as Power-Up Display
