1–4 Introduction
Publication 1397-5.0 — June, 2001
1397 – OPTIONS
CONTROL OPTIONS
–DS AC Line Disconnect
–MB Blower Motor Starter
–L10 Control Interface – 115VAC
–L11 I/O Expansion Cord
–DB Dynamic Braking
–FS 3 Enhanced Field Supply
–FS 2 Field Current Regulator
–PE Pulse Encoder Kit
–AC AC Tachometer Kit
–IFB (400 – 600 HP only)
HUMAN INTERFACE OPTIONS
–HAB Blank – No Functionality
–HAP Programmer Only
–HA1 Programmer / Controller with Analog Pot
–HA2 Programmer / Controller with Digital Pot
COMMUNICATION OPTIONS (Loose Kits)
–1203–GD1 Single Point Remote I/O (RIO) – 115V AC
–1203–GD2 RS–232/422/485, DF1 and DH485 Protocol – 115VAC
–1203–GK1 Single Point Remote I/O (RIO) – 24 VDC
–1203–GK2 RS–232 Interface Brd
–1203–GK5 DeviceNet – 24 VDC
OPTION CROSS REFERENCE
380/415VAC 460VAC
7A 3 HP
29A 15 HP
55A 30 HP
110A 60 HP
265A 150 HP
Input Voltage and Frequency Ratings
Nominal Voltage 207 to 253 V AC or 414 to 506 V AC
(Horsepower-rated drives)
342 to 437 V AC or 374 V AC to 477 V AC
(Current-rated drives)
Nominal Line Frequency 50 or 60 cycles per second
Frequency Variation + 2 cycles of nominal
AC Line Fault Capacity
Allowable AC Line Symmetrical (See Power Ratings and Supply Capacity)
AC Line kVA
AC Line Distribution Capacity Maximum 3 drives per transformer
Minimum Source kVA (See Power Ratings and Supply Capacity)
DC Voltage Ratings
230 V AC Line
Armature Voltage 240 V DC
Field Voltage (w/basic fld supply) 150 VDC
380/415 V AC Line
Armature Voltage 400/460 V DC
Field Voltage (w/basic fld supply) 250/270 VDC
460 V AC Line
Armature Voltage 500 V DC
Field Voltage (w/basic fld supply) 300 VDC
Service Factor Ratings
Service Factor 1.0 Continuous
Overload Capacity (drive only) 150% of full load rating for one minute
200% of full load rating for
13 seconds
Minimum Load 5% of rated load
Specifications
