OUTPUT CONFIG
[Dig Out 2 Src] — P.157
Only used if the I/O Expansion Kit is installed.
Selects the signal used to drive digital output
2 (terminals 68 and 69 on the I/O Expansion
board).
Display/Drive Units:
Numeric/Text
Parameter Range:
0 = Monitor1 Out
1 = Monitor2 Out
2 = In Cur Limit
3 = Drive Ready
Parameter Type:
Configurable
Group:
Output Config
Factory Default:
1
Minimum Value:
0
Maximum Value:
3
ATTENTION: This output is intended for use as an indication. DO
NOT use this as a control source. If it is used as a control source, a
dangerous condition can result. Failure to observe this precaution can
result in severe bodily injury or loss of life.
!
[Dig Out 2 Type] — P.158
Only used if the I/O Expansion Kit is installed.
Selects whether digital output 2 (terminals 68
and 69 on I/O Expansion board) is normally
open or normally closed.
Display/Drive Units:
Numeric/Text
Parameter Range:
0 = Normal Open
1 = Normal Closed
Parameter Type:
Configurable
Group:
Output Config
Factory Default:
0
Minimum Value:
0
Maximum Value:
1
ATTENTION: On a power cycle or reset, the contact is held at
normally open until the drive software is initialized. Make sure
that this condition does not result in a dangerous situation for
your application. Failure to observe this precaution can result
in severe bodily injury or loss of life.
!
If [Normal Open] is selected, digital output 2 is open when the signal is off and closed when it is on.
If [Normal Closed] is selected, digital output 2 is closed when the signal is off and open when it is on.
[Freq Out Scale] — P.159
Only used if the I/O Expansion kit is installed.
The frequency generated when the signal
driving the frequency output is at full scale.
For example, if [Freq Out Source] is set to
[Cur Lp Fdbk], the frequency specified by
this parameter is output when the armature
current is at [Maximum Current] —
[Maximum Current] is used as the basis for
current minor loop scaling.
Display/Drive Units:
kHz
Parameter Type:
Configurable
Group:
Output Config.
Factory Default:
250.0 kHz
Minimum Value:
2.0 kHz
Maximum Value:
250.0 kHz
Refererence Parameters:
[Freq Out Source] — P.160
[Maximum Current] — P.040
