Rockwell Automation 1397 DC Drive Firmware 2.xx - Manual (Page 113)

5–3 Programming Parameters
Publication 1397-5.0 — June, 2001
99–Min Speed Bypass (pg. 5–38)
100–Ref Ramp Bypass (pg. 5–38)
101–Current Compound (pg. 5–38)
102–Inertia Comp Src (pg. 5–39)
103–Monitor 1 Delay (pg. 5–39)
104–Monitor 1 Source (pg. 5–40)
105–Monitor 1 Level (pg. 5–40)
106–Monitor 2 Delay (pg. 5–41)
107–Monitor 2 Source (pg. 5–41)
108–Monitor 2 Level (pg. 5–42)
109–Normal Inertia (pg. 5–42)
110–Reverse Disable (pg. 5–42)
111–S–Curve Rounding (pg. 5–43)
112–AutoTune Bridge (pg. 5–43)
113–AutoTune Fld Rng (pg. 5–44)
114–AutoTune Stablty (pg. 5–44)
115–Stop Mode Type (pg. 5–44)
116–Stop Speed Level (pg. 5–44)
117–Trim Mode Type (pg. 5–45)
118–Trim Range (pg. 5–45)
119–Trim Ref Source (pg. 5–45)
120–Trim Reference (pg. 5–46)
121–OCL Enable Src (pg. 5–46)
122–Inertia Comp Reg (pg. 5–46)
FEATURE SELECT
84–MOP Accel Time (pg. 5–34)
85–MOP Decel Time (pg. 5–34)
86–MOP Reset Enable (pg. 5–34)
87–Preset Speed 1 (pg. 5–35)
88–Preset Speed 2 (pg. 5–35)
89–Preset Speed 3 (pg. 5–35)
90–Ref 1 Source (pg. 5–35)
91–Ref 2 Source (pg. 5–36)
92–Jog Acc/Dec Time (pg. 5–36)
93–Jog Reference (pg. 5–36)
94–Jog Off Dly Time (pg. 5–37)
REFERENCE SET
127–Anlg In 1 Gain (pg. 5–47)
128–Anlg In 1 Type (pg. 5–47)
129–Anlg In 1 Zero (pg. 5–47)
130–Anlg In 2 Gain (pg. 5–47)
131–Anlg In 2 Zero (pg. 5–48)
132–Anlg In 3 Gain (pg. 5–48)
133–Anlg In 3 Type (pg. 5–48)
134–Anlg In 3 Zero (pg. 5–49)
135–Anlg In 4 Gain (pg. 5–49)
136–Anlg In 4 Zero (pg. 5–49)
137–Freq In Scale (pg. 5–49)
138–Freq In Zero (pg. 5–50)
INPUT CONFIG
Parameter Groups
