5–98 Programming Parameters
Publication 1397-5.0 — June, 2001
Name No. See Page: Name No. See Page:
Encoder Fdbk 189 5–68 J18 Arm Fdbk Res 183 5–67
Encoder Kit 187 5–68 J20 Fld Loss Det 184 5–67
Encoder PPR 048 5–26 J21 Field Supply 185 5–67
Encoder Quad 049 5–27 Drive Status 191 5–69
Expansion I/O 178 5–65 AC Line Period 192 5–69
Exp I/O Dig In 195 5–70 Last Stop Cause 166 5–62
Fault Reset 196 5–70 Local Mask 208 5–74
Fault Reset Mask 205 5–73 Local Owner 221 5–77
Flt Reset Owner 219 5–77 Logic Mask 207 5–74
Feedback Type 039 5–23 Logic Status 190 5–69
Field Delta 174 5–64 Monitor 1 Delay 103 5–39
Field Feedback 010 5–16 Monitor 1 Level 105 5–40
Field Ref TP 176 5–65 Motor Field Amps 044 5–25
Fld Auto Weak 275 5–88 Monitor 1 Source 104 5–40
Fld Econ Active 175 5–64 Monitor 2 Delay 106 5–41
Field Regulator 177 5–65 Monitor 2 Level 108 5–42
Fld Delta Hi Lim 276 5–88 Maximum Current 040 5–23
Fld Econ Delay 273 5–87 Max Motor Speed 041 5–23
Fld Econ Ref 274 5–87 Max Process Spd 042 5–24
Fld Lp Lead Freq 278 5–89 Min Process Speed 043 5–24
Fld Loop K–Fdbk 281 5–90 Min Speed Bypass 099 5–38
Fld Loop Kp 279 5–89 Monitor 1 Output 013 5–17
Fld Loss Level 277 5–89 Monitor 2 Output 014 5–17
Field Reference 280 5–90 Motor Field Amps 044 5–25
Fld Weak Ld Freq 282 5–90 MOP Accel Time 084 5–34
Fld Weaken Kp 283 5–90 MOP Decel Time 085 5–34
Fld Weaken Level 284 5–90 MOP Mask 206 5–73
Frequency In 011 5–16 MOP Output 015 5–17
Frequency In Scale 137 5–49 MOP Reset Enable 086 5–34
Freq In Zero 138 5–50 MOP Owner 220 5–77
Freq Out Src 160 5–61 Motor Arm Amps 045 5–25
Freq Out Scale 159 5–60 Motor Arm Volts 046 5–26
Freq Out Zero 161 5–62 Neg Current Lim 068 5–30
IR Compensation 066 5–30 Neg Cur Lim Src 070 5–31
Inertia Comp Src 102 5–39 Normal Inertia 109 5–42
Inertia Comp Reg 122 5–46 Nominal AC Freq 050 5–27
IR Comp TP 179 5–65 Nominal AC Volt 051 5–27
Jog Acc/Dec Time 092 5–36 NOT Ready Cause 199 5–71
Jog Mask 203 5–72 OCL Enable TP 016 5–18
Jog Owner 217 5–76 OCL Enable Src 121 5–46
Jog Ramp Output 012 5–17 OCL Feedback 017 5–18
Jog Reference 093 5–36 OCL Fdbk Reg 304 5–96
Jog Off Dly Time 094 5–37 OCL Fdbk Source 290 5–91
J11 Tach V Scale 180 5–66 OCL Kp 294 5–92
J14 Tach V Range 181 5–66 OCL LeadLag Ratio 292 5–92
J15 Reg Type 182 5–66 OCL LeadLag Type 293 5–92
