5–14 Programming Parameters
Publication 1397-5.0 — June, 2001
This section provides a list of 1397 parameters sorted into their
respective parameter groups with their associated default values,
Display/Drive units, description and group designation and any
applicable enums.
Tunable – Parameter can be changed while the drive is running.
Configurable – Parameter can only be changed when the drive is
not running.
To help differentiate parameter names and display text from other
text in this manual, the following conventions will be used:
D Parameter names will appear in [Brackets]
D Display text will appear in “quotes”.
METERING
[Anlg In 1] — P.001
Analog reference 1 value measured by the
drive after all hardware and software scaling. Display/Drive Units: RPM
Group: Metering
Parameter Type Output
Factory Default 0
Minimum Value –5369
Maximum Value 5369
[Anlg In 2] — P.002
Analog reference value measured by the
drive after all hardware and software scaling. Display/Drive Units: RPM
Group: Metering
Parameter Type: Output
Factory Default 0
Minimum Value –5369
Maximum Value 5369
[Anlg In 3] — P.003
Only used if the I/O Expansion kit is installed.
The value representing analog input 3
(terminals 50 and 51 on the I/O Expansion
board) after gain and zero have been applied.
Refer to the I/O Expansion Inputs (Fig. A.2)
block diagram for additional information.
Display/Drive Units: CNTS
Group: Metering
Parameter Type Output
Factory Default 0
Minimum Value –5369
Maximum Value 5369
Parameter Descriptions
(By Parameter Group)
