5–6 Programming Parameters
Publication 1397-5.0 — June, 2001
Table 5.A
1397 Parameters
PARM NAME
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
Anlg In 1
Anlg In 2
Anlg In 3
Anlg In 4
Armature Voltage
Cur Loop Fdbk
Cur Loop Error
Cur Loop Ref
Draw Percent Out
Field Feedback
Frequency In
Jog Ramp Output
Monitor 1 Output
Monitor 2 Output
MOP Output
OCL Enable TP
OCL Feedback
OCL Output
OCL Ramp Output
OCL Reference TP
Spd Loop Error
Spd Loop Fdbk
Spd Loop Lag Out
Spd Loop Output
Spd Loop Ref
Spd Src Output
Spd Ramp In TP
Spd Ramp Output
Speed Pot
Trim Output
Torque Reference
METERING 1
METERING 2
METERING 3
METERING 4
CT Turns Ratio
Accel Time
Decel Time
UNITS
RPM
RPM
Counts
Counts
Volts
Amps
Amps
Amps
%
Amps
KHZ
RPM
RPM
CNTS
RPM
CNTS
CNTS
RPM
RPM
RPM
AMPS
RPM
RPM
RPM
RPM
RPM
RPM
AMPS
(Hidden)
(Hidden)
(Hidden)
(Hidden)
TP/TN
Seconds
Seconds
MIN MAX DEFAULT FUNCTION
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Metering
Setup
Setup
Setup
TYPE
Configurable
Tunable
Tunable
–5369
–5369
–5369
–5369
–675
–2400
–3840
–4440
+/– 0.10
–0.0
–2000
–5000
0 (OFF)
0 (OFF)
–5000
0 (Disabled)
–5120
–5000
–4095
–4095
–8190
–4095
–4095
–1440
–5000
–5000
–5000
–5000
–5000
–5000
–960
FUTURE
FUTURE
FUTURE
FUTURE
1
0.1
0.1
5369
5369
5369
5369
675
2400
3840
1440
+/–100.0
20.0
2000
5000
1 (ON)
1 (ON)
5000
1 (Enable)
5120
5000
4095
4095
8190
4095
4095
1440
5000
5000
5000
5000
5000
5000
960
USE
USE
USE
USE
32767
300
300
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0.00
0
0
0
0
0
0
0
NA
5.0
5.0
Numeric Parameter Table
