5–27 Programming Parameters
Publication 1397-5.0 — June, 2001
SETUP
[Encoder Quad] — P.049
Enables or disables encoder quadrature.
Encoder quadrature must be used on
regenerative drives that use an encoder.
Set On for a bidirectional encoder.
Set Off for a unidirectional encoder.
Display/Drive Units: Numeric/Text
Parameter Type: Configurable
Group: Setup
Factory Default: 1
Minimum Value: 0 (Off)
Maximum Value: 1 (On)
If [Encoder Quad] is set to Off and Pulse Tach is the selected [Feedback Type] type, [Neg Current Lim] will be set to 0 and [Reverse Disable]
set to On (preventing reverse direction).
[Nominal AC Freq] — P.050
The nominal AC line frequency (typically 50
or 60 Hz). Display/Drive Units: Hz
Parameter Type: Configurable
Group: Setup
Factory Default: 60
Minimum Value: 48
Maximum Value: 62
[Nominal AC Volt] — P.051
The nominal AC line RMS voltage. Display/Drive Units: V AC
Parameter Type: Configurable
Group: Setup
Factory Default: 230
Minimum Value: 200
Maximum Value: 575
[AutoTune Type] — P.052
When the Drive is “Ready”, this parameter
allows selection of the Auto Tune Mode.
After selection is made, pressing Run will
start the tuning mode.
Display/Drive Units: Numeric/Text
Parameter Type: Configurable
Group: Setup
Factory Default: 0
Minimum Value: 0
Maximum Value: 3
Enums: 0 = None, 1 = Current+Spd, 2 = Current Loop, 3 = Spd Loop
