5–17 Programming Parameters
Publication 1397-5.0 — June, 2001
METERING
[Jog Ramp Output] — P.012
An output that represents the jog reference
value immediately after the jog ramp function. Display/Drive Units: RPM
Group: Metering
Type: Read Only
Factory Default: 0
Minimum Value: –5000
Maximum Value: 5000
[Monitor 1 Output] — P.013
Shows the present state of the respective
monitor (On, Off). Display/Drive Units: Enum Text
Group: Metering
Factory Default: 0
Minimum Value: 0 (Off)
Maximum Value: 1 (On)
[Monitor 2 Output] — P.014
Shows the present state of the respective
monitor (On, Off). Display/Drive Units: Enum Text
Group: Metering
Factory Default: 0
Minimum Value: 0 (Off)
Maximum Value: 1 (On)
[MOP Output] — P.015
The output of the motor operated
potentiometer (MOP).
Refer to the [MOP Accel Time] input
parameter and block diagram for additional
information.
Display/Drive Units: RPM
Group: Metering
Parameter Type: Read Only
Factory Default: 0
Minimum Value: –5000
Maximum Value: 5000
