5–100 Programming Parameters
Publication 1397-5.0 — June, 2001
The parameters shown in the following table are unused and are
hidden in 1397 Drives with V 1.XX or greater firmware. These
parameters are for future expansion of functions in the Drive and
have no effect on Drive operation. These parameters are neither
visible nor accessible through the HIM. When using DriveTools or
DeviceNet manager, however, all parameters can be seen (even ones
marked as hidden). While visible, they are not functional.
Hidden Parameter Name No. Hidden Parameter Name No.
Metering 1 032 OUT CFG 4 165
Metering 2 033 MASKS 1 209
Metering 3 034 MASKS 2 210
Metering 4 035 MASKS 3 211
Setup 2 053 MASKS 4 212
Setup 3 054 MASKS 5 213
Setup 4 055 OWNERS 2 222
Setup 5 056 OWNERS 3 223
Metering 5 065 OWNERS 4 224
ADV SETUP 2 080 ADAPT IO 1 242
ADV SETUP 3 081 ADAPT IO 2 243
ADV SETUP 4 082 ADAPT IO 3 244
ADV SETUP 5 083 ADAPT IO 4 245
REF SETUP 2 095 ADAPT IO 5 246
REF SETUP 3 096 PROC DISP 1 267
REF SETUP 4 097 PROC DISP 2 268
REF SETUP 5 098 PROC DISP 3 269
FEATR SEL 1 122 PROC DISP 4 270
FEATR SEL 2 123 PROC DISP 5 271
FEATR SEL 3 124 FIELD 1 285
FEATR SEL 4 125 FIELD 2 286
FEATR SEL 5 126 FIELD 3 287
IN CFG 1 082 FIELD 4 288
IN CFG 2 083 FIELD 5 289
IN CFG 3 095 PROC PI 2 305
IN CFG 4 096 PROC PI 3 306
IN CFG 5 097 PROC PI 4 307
OUT CFG 1 098 PROC PI 5 308
OUT CFG 3 123
Hidden Parameters
