5–70 Programming Parameters
Publication 1397-5.0 — June, 2001
DIAGNOSTICS
[AC Line Voltage] — P.193
Shows AC line voltage as measured by the
drive. Display/Drive Units: VAC
Parameter Type: Read Only
Group: Diagnostics
Factory Default: None
Minimum Value: 200
Maximum Value: 575
[Analog Tach Fdbk] — P.194
The digital value of the analog tachometer
feedback input after all hardware and
software scaling. For use with analog
tachometer feedback (AC or DC) only. Display/Drive Units: RPM
Parameter Range: N/A
Parameter Type: Output
Group: Diagnostics
Factory Default: 0
Minimum Value: –4095
Maximum Value: 4095
[Exp I/O Dig In] — P.195
Only used if the I/O Expansion kit is installed.
Shows the state of all I/O expansion digital
inputs (terminals 59–64 on the I/O Expansion
board). The input is On when + 24 V DC is
applied for more than 20 mS. It is Off when 0
V DC is applied. Information is displayed in
binary format.
Display/Drive Units: Numeric/Text
Parameter Range: Bit # Enum Text Bit # Enum Text
0 = Preset A 3 = Increment
1 = Preset B 4 = OCL Enable
2 = Decrement
Factory Default: 0
Minimum Value: 0
Maximum Value: 4
X X X __ __ __ __ __
Preset B
Preset A
MOP Dec
MOP Inc
OCL Enable
[Fault Reset] — P.196
Allows resetting of the fault or alarm through
the HIM. Display/Drive Units: Numeric/Text
Parameter Range: 0 = Ready 1 = Reset
Group: Diagnostics
Minimum Value: 0
Factory Default: 0
Maximum Value: 1
