5–26 Programming Parameters
Publication 1397-5.0 — June, 2001
SETUP
[Motor Arm Volts] — P.046
The rated armature voltage from the motor
nameplate. Display/Drive Units:
Parameter Type: Configurable
Group: Setup
Factory Default: 240
Minimum Value: 160
Maximum Value: 675
ATTENTION: The incorrect setting of this parameter can cause an
overspeed condition. This parameter must be set by a qualified person
who understands the significance of setting it. set the value of this
parameter accurately per your application requirements. Failure to
observe this precaution could result in bodily injury.
!
[Anlg Tach V/1000] — P.047
The analog tachometer scaling from the
tachometer nameplate in volts per 1000 RPM.
Units are volts DC for DC tachometers or volts
AC RMS for AC tachometers.
Note: The use of an AC tachometer requires
the AC Tachometer Feedback kit.
Display/Drive Units: V/1K
Parameter Type: Configurable
Group: Setup
Factory Default: 18.0/1000 RPM
Minimum Value: 18.0
Maximum Value: 200.0
Note: The high limit might be less than 200.0 to prevent the tach voltage from exceeding 250V.
ATTENTION: The incorrect setting of this parameter can cause an
overspeed condition. This parameter must be set by a qualified person
who understands the significance of setting it. Set the value of this
parameter accurately per your application requirements. Failure to
observe this precaution could result in bodily injury.
!
[Encoder PPR] — P.048
Encoder pulses per revolution (PPR) from the
encoder nameplate. Display/Drive Units: PPR
Parameter Type: Configurable
Group: Setup
Factory Default: 18
Minimum Value: 18
Maximum Value: 2500
ATTENTION: The incorrect setting of this parameter can cause an
overspeed condition. This parameter must be set by a qualified person
who understands the significance of setting it. Set the value of this
parameter accurately per your application requirements. Failure to
observe this precaution could result in bodily injury.
!
