5–72 Programming Parameters
Publication 1397-5.0 — June, 2001
MASKS
[Start Mask] — P.201
This parameter controls which adapters can
issue Run commands. Display/Drive Units: Numeric/Text
Parameter Range: Bit # Enum Text
0 = Terminal Block
1 = Adapter 1
2 = Adapter 2
3 = Adapter 3
4 = Adapter 4
5 = Adapter 5
6 = Adapter 6
Parameter Type: Read & Write
Group: Masks
Minimum Value: 0000000000000000
Factory Default: 0000000001111111
Maximum Value: 0000000001111111
[Direction Mask] — P.202
This parameter controls which adapters can
issue forward/reverse commands. This mask
contains a bit for each adapter. If a bit is set
to 0 control is locked out, if it is set to 1, the
adapter is permitted to have control. Display/Drive Units: Numeric/Text
Parameter Range: Bit # Enum Text
0 = Terminal Block
1 = Adapter 1
2 = Adapter 2
3 = Adapter 3
4 = Adapter 4
5 = Adapter 5
6 = Adapter 6
Group: Masks
Minimum Value: 0000000000000000
Factory Default: 0000000001111111
Maximum Value: 0000000001111111
[Jog Mask] — P.203
This parameter controls which adapters can
issue jog commands. Display/Drive Units: Numeric/Text
Parameter Range: Bit # Enum Text
0 = Terminal Block
1 = Adapter 1
2 = Adapter 2
3 = Adapter 3
4 = Adapter 4
5 = Adapter 5
6 = Adapter 6
Parameter Type: Read & Write
Group: Masks
Minimum Value: 0000000000000000
Factory Default: 0000000001111111
Maximum Value: 0000000001111111
