Rockwell Automation 1397 DC Drive Firmware 2.xx - Manual (Page 11)

1–3 Introduction
Publication 1397-5.0 — June, 2001
Drive specific data, such as horsepower (or output current),
regenerative or non-regenerative type, line voltage etc. can be
determined by the Drive model number. The model number structure
is shown below.
1397– B005 – OPTIONS
1397 – B
1397
First Position
Bulletin Number Second Position
Voltage
Letter
A 230V AC
Voltage Rating
001
002
003
005
007
010
015
020
025
030
040
050
060
075
100
125
150
HP (kW)
1.5 (1.1)
2 (1.5)
3 (2.2)
5 (3.7)
7.5 (5.8)
10 (7.5)
15 (11)
20 (15)
25 (18)
30 (22)
40 (29)
50 (37)
60 (44)
75 (55)
100 (74)
125 (93)
150 (111)
N = Non Regen
R = Regen
1
005
Third Position
Rating
R
Fourth Position
Type
– OPTIONS
Fifth Position
B 460V AC 003
005
007
010
015
020
025
030
040
050
060
075
100
125
150
200
250
300
400
500
600 3 (2.2)
5 (3.7)
7.5 (5.6)
10 (7.5)
15 (11)
20 (15)
25 (18)
30 (22)
40 (29)
50 (37)
60 (44)
75 (55)
100 (74)
125 (93)
150 (111)
200. (149)
250 (186)
300 (224)
400 (298)
500 (373)
600 (448)
–DS
–MB
–L10
–L11
–DB
–FS2
–FS3
–PE
–AC
–HAB
–HAP
–HA1
–HA2
1203–GD1
1203–GD2
1203–GK1
1203–GK2
1203–GK5
NOTE: Refer to page
1–4 for additional option
information.
U 380/415V AC ADC
7
29
55
110
265 380/415
2.4 (1.8)/2.8 (2.1)
12 (9)13.8 (10.3)
24 (17.9)/27.6 (20.8)
48 (35.8)/55.2 (41.2)
120 (89.5)/138 (102.9)
1 Regen (R) required for reversing applications
Catalog Numbering
Convention
