Programming and Parameters

3-49

Enhanced Program Group

E201 [LED Display Opt]

Selects which parameters can be viewed by the drive’s LED interface.

Values

Default:

2

Min/Max:

0/3

Display:

1

E201 Option

Parameter Set

0
1
2
3

All Basic Display (Group b) and Advanced Display (Group d) parameters
All Basic Display Group (b001-b029) parameters
Basic Display Group parameters b001-b007 and b010
Basic Display Group parameter b001-b004

E202 [Digital Term 3]

Stop drive before changing this parameter.

Sets the function of I/O Terminal 03.

Options

0 “Start Source” (Default) Input functions as defined by

P036

[Start Source].

1 “Acc/Dec Sel1”

If active, can determine which Accel/Decel time will be used
for all ramp rates except jog. Can be applied to one input
only. Refer to

A067

[Accel Time 2] for details.

2 “Jog”

When input is present, drive accelerates according to the
value set in

A079

[Jog Accel/Decel] and ramps to the

value set in

A078

[Jog Frequency].

When input is removed, drive ramps to a stop according to
the value set in

A079

[Jog Accel/Decel].

A valid “Start” command will override this input.

3 “Aux Fault”

When enabled, an F2

Auxiliary Input

fault will occur when the

input is removed.

4 “Preset Freq”

Refer to

A070

-

A077

[Preset Freq x].

Important: Digital Inputs have priority for frequency control
when programmed as Preset Speed and are active. Refer to
the flowchart on

page 1-27

for more information on speed

reference control priority.

5 “Reserved”

6 “Comm Port”

When active, sets communications device as default start/
speed command source.

Can only be tied to one input.

7 “Clear Fault”

When active, clears an active fault.

8 “RampStop,CF”

Causes drive to immediately ramp to a stop regardless of how

P037

[Stop Mode] is set.

9 “CoastStop,CF”

Causes drive to immediately coast to a stop regardless of
how

P037

[Stop Mode] is set.

10 “DCInjStop,CF”

Causes drive to immediately begin a DC Injection stop
regardless of how

P037

[Stop Mode] is set.
