Rockwell Automation 22D PowerFlex 40P User Manual, FRN 3 - Manual (Page 138)

B-8 Accessories and Dimensions
Figure B.2 IP 30/NEMA 1/UL Type 1 Option Kit with Communication Option –
Dimensions are in millimeters and (inches)
180
(7.09)
244
(9.61)
168
(6.61)
100.0 (3.94)
87.0 (3.43) 136.0 (5.35)
161.0 (6.34)
∅
22.2
(0.87)
RUN
REV
FAULT
RUN
REV
FAULT
87.4
(3.44)
76.3
(3.00)
105.3
(4.15)
134.3
(5.29)
50.0 (1.97)
77.5 (3.05)
22.5 (0.89)
260
(10.2)
320
(12.6)
246
(9.7)
130.0 (5.1)
116.0 (4.57)
180.0 (7.1)
205.0 (8.07)
RUN
REV
FAULT
45.7 (1.80)
109.8
(4.32)
144.8
(5.70)
179.8
(7.08)
69.2 (2.72)
92.2 (3.63)
108.7 (4.28)
22.2 (0.87) ∅
22.2
(0.87)
∅
28.5
(1.12)
Frame B - 22-JBCB
Frame C - 22-JBCC
