Programming and Parameters
3-17
A051 -
A054
Options
(Cont.)
29 “Precharge En”
Forces drive into precharge state. Typically controlled by
auxiliary contact on the disconnect at the DC input to the
drive. If this input is assigned, it must be energized for the
pre-charge relay to close and for the drive to run. If it is
de-energized, the pre-charge relay will open and the drive will
coast to a stop.
30 “Inertia Dcel”
Forces drive into Inertia Ride-Through state. The drive will
attempt to regulate the DC bus at the current level.
31 “Sync Enable”
Must be used in order to hold the existing frequency when
Sync Time is set to enable speed synchronization. When this
input is released the drive will accelerate to the commanded
frequency in
E214
[Sync Time].
32 “Traverse Dis”
When an input is programmed the traverse function will be
disabled while this input is active. Refer to
[Max
Traverse].
33 “Home Limit”
In Positioning mode, this indicates the drive is at the home
position. Refer to
for detailed information on
positioning.
34 “Find Home”
In Positioning mode this causes the drive to return to the
Home position when a start is issued. It does this by using the
[Find Home Freq] and [Find Home Direction] until the “Home
Limit” input is activated. If it passes this point, it then runs in
the reverse direction at 1/10th the frequency of [Find Home
Freq] until the “Home Limit” is activated again. As long as this
input is active, any start command will cause the drive to
enter the homing routing. Only functions if in Positioning
mode. Once the Find Home routine has finished, the drive will
stop. Refer to
positioning.
35 “Hold Step”
In Positioning mode, this input over-rides other inputs and
causes the drive to remain at its current step (running at zero
speed once it reaches its position) until released. While in
“Hold”, the drive will ignore any input command which would
normally result in a move to a new step. Timers continue to
run. Therefore, when the Hold is removed, the drive must see
any required digital inputs transition (even if they already
transitioned during the hold), but it does not reset any timer.
Refer to
for detailed information on positioning.
36 “Pos Redefine”
In Positioning mode, this input resets the home position to the
current position of the machine. Refer to
for
detailed information on positioning.
