Accessories and Dimensions B-9
Figure B.3 PowerFlex 40P Flange Mount Drives – Dimensions are in millimeters and
(inches)
244
(9.61)
250
(9.84)
94.3
(3.71)
63.1
(2.48)
214
(8.43)
106.3
(4.19)
RUN
REV
FAULT
RUN
REV
FAULT
20A-DG01
119.3
(4.70)
22D-CCB
138.2
(5.44)
105.8
(4.17)
325
(12.8)
300
(11.81)
117.8
(4.64)
130.3
(5.13)
RUN
REV
FAULT
RUN
REV
FAULT
20A-DG01
22D-CCC
Frame B
Frame C
