P-4 Overview
Catalog Number Explanation
Code Voltage Ph.
B 240V AC 3
D 480V AC 3
E 600V AC 3
Code Version
4
Standard
Code HIM Version
1
Display/Fault Reset Only
2 Display/Fault Reset Only (Plate Drive)
Code Enclosure
N
Panel Mount - IP 20 (NEMA Type Open)
F Flange Mount - IP 20 (NEMA Type Open)
H Plate Drive - IP 20 (NEMA Type Open)
1-3 4 5 6-8 9 10 11
12
13-14
22D - B 2P3 N 1 0 4 AA
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Version Optional
Code EMC Filter
0
Not Filter
Output Current @ 380-480V Input
Code Amps kW (HP)
1P4 1.4 0.4 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
010 10.5 4.0 (5.0)
012 12 5.5 (7.5)
017 17 7.5 (10)
024 24 11 (15)
Code
22D
PowerFlex 40P
Additional accessories, options and adapters are available. See Appendix B for details.
Output Current @ 460-600V Input
Code Amps kW (HP)
1P7 1.7 0.75 (1.0)
3P0 3.0 1.5 (2.0)
4P2 4.2 2.2 (3.0)
6P6 6.6 4.0 (5.0)
9P9 9.9 5.5 (7.5)
012 12 7.5 (10)
019 19 11 (15)
Code Purpose
AA
Reserved for
thru custom firmware
ZZ
Output Current @ 200-240V Input
Code Amps kW (HP)
2P3 2.3 0.4 (0.5)
5P0 5.0 0.75 (1.0)
8P0 8.0 1.5 (2.0)
012 12 2.2 (3.0)
017 17.5 3.7 (5.0)
024 24 5.5 (7.5)
033 33 7.5 (10)
