Programming and Parameters
3-37
Advanced Program Group
(continued)
A113 [Anlg In4-20mA Hi]
Related Parameter(s):
,
Stop drive before changing this parameter.
Sets the analog input level that corresponds to
[Maximum Freq] if a 4-20mA input is used by
[Speed Reference].
Analog inversion can be accomplished by setting this value smaller than A112 [Anlg In4-20mA Lo].
Values
Default:
100.0%
Min/Max:
0.0/100.0%
Display:
0.1%
A114 [Slip Hertz @ FLA]
Related Parameter(s):
Compensates for the inherent slip in an induction motor. This frequency is added to the commanded
output frequency.
Values
Default:
2.0 Hz
Min/Max:
0.0/10.0 Hz
Display:
0.1 Hz
A115 [Process Time Lo]
Scales the time value when the drive is running at
[Minimum Freq]. When set to a value other
than zero,
[Process Display] indicates the duration of the process.
Values
Default:
0.00
Min/Max:
0.00/99.99
Display:
0.01
A116 [Process Time Hi]
Scales the time value when the drive is running at
[Maximum Freq]. When set to a value other
than zero,
[Process Display] indicates the duration of the process.
Values
Default:
0.00
Min/Max:
0.00/99.99
Display:
0.01
A117 [Bus Reg Mode]
Controls the operation of the drive voltage regulation, which is normally operational at decel or when
the bus voltage rises.
Refer to the Attention statement on page
for important information on bus regulation.
Options
0 “Disabled”
1 “Enabled” (Default)
A118 [Current Limit 2]
Related Parameter(s):
-
Maximum output current allowed before current limiting occurs. This parameter is only active if
-
[Digital Inx Sel] is set to 25 “Current Lmt2” and is active.
Values
Default:
Drive Rated Amps
×
1.5
Min/Max:
0.1/(Drive Rated Amps
×
1.8)
Display:
0.1 Amps
