GDS-200 & GDS-300 Series User Manual

70

50%

Sets the trigger level to 50% of the
waveform amplitude.

Source

CH1, CH2

Channel 1 or channel 2 input.

Coupling (Edge,
Pulse only)

DC

Sets the coupling to DC.

AC

Sets the coupling to AC.

Slope (Edge only) Rising

Trigger on rising edge.

Falling

Trigger on falling edge.

Either

Trigger on either rising or falling
edge.

Reject

Off

Frequency rejection turned off.

LFR

Low frequency rejection.

HFR

High frequency rejection.

NR

Noise rejection

Holdoff

Holdoff

Sets the holdoff time. The holdoff
time delays triggering the next
waveform for a set amount of time
after triggering.

Polarity (Pulse)

Positive polarity

Positive polarity (triggered on the
high to low transition)

Negative
polarity

Negative polarity (triggered on the
low to high transition)

Polarity (Video)

Positive polarity

Positive polarity.

Negative
polarity

Negative polarity.

Trigger When
(Pulse)

=

Equal to.

>

Longer than.

<

Shorter than.

Not equal to.
