APPENDIX

181

GDS-200/300 Specifications

The specifications apply when the GDS-200/GDS-300 is powered
on for at least 30 minutes.

Scope Specifications

Vertical

Channel

2 (BNC-Shield)

Input Impedance

1MΩ

Maximum Input

CATII 300VRMs

Input Coupling

AC, DC, GND

Bandwidth

DC-70/100/200MHz (-3dB)

Rise Time

<5ns / 3.5ns / 1.75ns approx.

Sensitivity

2mV/div-10V/div (1-2-5 increments)

Accuracy

±(3% x Readout + 0.1 div + 1mV)

Bandwidth Limit

20MHz(-3dB)

Polarity

Normal, Invert

Offset Position Range 2mV/div-50mV/div : ±0.4V

100mV/div-500mV/div : ±4V
1V/div-5V/div : ±40V
10V/div : ±300V

Signal Acquisition

Realtime Sample Rate 1GSa/s
Memory Depth

5M points per channel (GDS-307/310/320)
1M points per channel (GDS-207/210/220)

Acquisition Mode

Average: 2-256 waveforms
Peak detect: 10ns
sin(x)/x or ET

Replay wfms.

30,000 wfms

Trigger

Source

Ch1 or Ch2

Trigger Mode

Auto, Normal, Single, Force

Trigger Type

Edge, Pulse width, Video, Alternative

Trigger Holdoff

10ns - 10s

Coupling

AC, DC, LFR, HFR, NR
