Set the Interpolation

Background

The GDS-200/GDS-300 has two types of
interpolation modes: ET (Equivalent Time) and
Sin(x)/x interpolation. Equivalent time
sampling is able to achieve a sample rate of
20GSa/s when sampling periodic waveforms.
Sin(x)/x interpolation uses a sinc interpolation
formula to reconstruct a continuous signal
between sampled points.

Sin(x)/x

Samples of data are used to
reconstruct a single waveform.
Sin(x)/x sampling should be
used when the time base is fast
or if single shot events need to be
captured.

Equivalent-
time sampling

Sampled data is accumulated a
number of times to reconstruct a
single waveform. This increases
the sampling rate, but can only
be used for repetitive signals.
This mode is usually used when
the time base is too fast for real-
time sampling.

Steps

From the Acquire menu, press Interpolation
and select the interpolation method.

Interpolation

ET, sin(x)/x

Interpolation

menu
