OPERATION
41
Gesture Control
This chapter will go over all of the basic touch gestures that are
available using the default settings. The touch gestures cover all the
most frequently used operations that an engineer uses, allowing the
GDS-200/300 to operate completely without panel keys or knobs.
Note
The gestures described below are only applicable if
“Waveform” is selected as the gesture control method.
See page 83 for details.
Select a Channel, Math or Reference Waveform
Background Any channel, math waveform or reference
waveform that has already been turned on can be
selected from the left of the grid. See page 51 to
turn on a waveform, math function or waveform.
Steps To select the active waveform, tap the desired
channel, math or reference indicator.
When selected, the icon will become a solid
triangle.
Example
Selected
waveform
