Sensitivity

DC - 25MHz: approx. 0.5div or 5mV
25MHz - 70/100/200MHz: approx. 1.5div or 15mV

Horizontal

Range

5ns-100s/Div (1-2-5 increments)

Roll

100ms/div - 100s/div

Pre-Trigger

10 div max.

Post-Trigger

1,000 div max (depend on time base)

Accuracy

±20ppm over any > 1ms time interval

X-Y Mode

Phase Shift

±3° at 100kHz

Cursors and Measurement

Cursors

Voltage difference between cursors(△V), time difference
between cursors(△T), frequency measure(1/△T)

Auto-measurement

36 sets

Auto-counter

6 digits. Range: 2Hz to rated bandwidth

Autoset

Available

Miscellaneous

Multi-language Menu Available
On-line Help

Available

Time and Clock

Available

Battery

Battery Power

Li-polymer 6100mA/hr, 7.4V (Built-in)

Charge Time

2.0 hour (75%)

Operation Time

4.1 hours, depending on the operating conditions.

Probe Compensation

2V, 1kHz, 50% Duty cycle

Interface

USB

USB Device (Isolated)

Internal Flash Disk

120MB
