Acquire Menu
The Acquire Menu sets the acquisition mode, channel mapping (XY
mode), record length and the sample interpolation type.
Accessing the Acquisition Menu
From the main screen, press the title bar to bring up the Drop Down
menu. Press the Acquire icon to show the Acquire menu
Menu tray
App tray
Acquire
