GETTING STARTED
15
Appearance
GDS-200/300 Front Panel
V
W
COM A mA
GDS-220 Digital Storage Oscilloscope
200 MHz 1GSa/s
FUSED
10A MAX
FUSED
CAT II 600mA MAX 600V
CAT III 300V
Display
COM port
Current ports
BNC inputs
Interface
panel
port V W
Display Color LCD screen, 800 x 480, capacitive touch.
Interface Panel The interface panel holds a number of different
interfaces such as the input power socket, USB
device port and the options power port. See page
18 for details.
