GDS-200 & GDS-300 Series User Manual

130

5. If All Displayed waveforms are to be saved,

then the following destination options are
available:

File Manager

Pressing File will allow you to
change the file path from the root
directory of the internal disk.

Rename

Pressing Rename will allow you
to rename the default directory
from ALXXXX.

File Format

6. Press File Format to select the save file format:

LSF

Internal file format. This format
saves and recalls waveforms the
fastest.

Fast CSV

Comma separated values. Allows
the waveforms to be saved in a
format that is readable by
spreadsheets.

Note

Fast CSV files can only be recalled if the record
length is 1k or 10k.

Adding Notes

A text file note can be added to the same file
path as the saved waveform file.

7. Press Note. The on-screen keyboard will

appear. Enter your note and press OK when
finished. See page 48 for details on using the
on-screen keyboard.

When the waveform file is saved, the note will
be saved as a text file (*.txt) into the same file
path and with the same base filename as the
image file.
