Set the waveform intensity – GW Instek GDS-200 Series User Manual User Manual
Page 114
GDS-200 & GDS-300 Series User Manual
114
Set the Waveform Intensity
Background
The intensity level of a signal can also be set to
mimic the intensity of an analog oscilloscope by
setting the digital intensity level.
Steps
From the Display menu press Waveform
Intensity and select the intensity level.
Waveform Intensity
0 - 100%
Waveform
Intensity
Menu
