background image

APPENDIX

183

Display

Type

7 Inch

Display Resolution

480 x 800

Display Orientation

Landscape and Portrait

Backlight Control

Manual adjustable & ECO mode

Touch Panel

Capacitive

Power Adapter

Line Voltage

AC 100V-240V, 47-63Hz, Power Consumption 40W

DC Output

12V/3A, double shielded wire cable

Dimensions and Weight

Weight

1.5kg

Dimensions

HxWxD(mm) 240.2mm x 136.0mm x 59.7 mm

DMM Specifications

Basic

Reading

50,000 counts, 4½ digits (GDS-307/310/320)
3½ digits (GDS-207/210/220)

Voltage Input

CAT II 600VRMS, CAT III 300VRMS

DC Voltage

Range

50mV, 500mV, 5V, 50V, 500V, 1000V, 6 ranges

Accuracy

GDS-307/310/320: 50mV, 500mV, 5V, 50V, 500V ±(0.05% +
5 digits), 1000V ±(0.1% + 5 digits)
GDS-207/210/220: 50mV, 500mV, 5V, 50V, 500V, 1000V
±(0.1% + 5 digits)

Input Impedance

10MΩ

DC Current

Range

50mA, 500mA, 10A, 3 ranges

Accuracy

GDS-307/310/320: 50mA - 500mA, 2 Ranges, ±(0.1% + 5
digits), 10A ±(0.5% + 1 digits)
GDS-207/210/220: 50mA - 500mA, 10A 3 Ranges, ±(0.5% +
1 digits)
