background image

REMOTE CONTROL CONFIG

165

Interface Configuration

The GDS-200/300 uses the USB device port for remote control.
When using the remote control function, the GDS-200/300 acts as a
virtual COM port (VCP).

Note

New drivers can be downloaded from the GW Instek
website,

www.gwinstek.com

.

Configure USB Interface

Configuration

PC side connection
GDS side connection

Type A, host port
Type Mini-B, device port

Background

The GDS’s USB device port needs to be
configured to the “Communication” mode to
enable the remote connection.

Configuration

1. Connect the PC to the GDS-200/300 using the

supplied USB-A to USB Mini-B cable.

2. From the Drop Down menu press the Utility

icon>USB device port and select
Communication. (See page 102).

3. When the PC asks for the USB driver, select the

USB driver included on the accompanying User
Manual CD or download the driver from the
GW Instek website, www.gwinstek.com. The
driver automatically sets the GDS-200/300 as a
virtual COM port.

4. The DSO should now be ready for remote

control. See page 166 for the remote control
function check.
