OPERATION

135

Recall Operations

The Recall function configures the save file destination, file format
and in the case of image files, the on-screen items that should be
saved.

Note

Files can only be recalled if the USB port is
configured to “Communication”. See page 102
for details.

Accessing the Recall Menu

From the main screen, press the title bar to bring up the Drop Down
menu. Press the Recall icon to show the Recall menu.

Menu tray

App tray

Recall

Recalling Waveform Files

Background

Waveforms can be recalled from either the
internal memory slots (wave1 - wave20) or files
saved in the LSF or CSV file formats.
