APPENDIX

179

Multiplier

Letter Code

Multiplier

Letter Code

Multiplier

F

10

5

B

10

1

E

10

4

A

10

0

D

10

3

X or S

10

-1

C

10

2

Y or R

10

-2

Example: 01A = 100Ω

2%, 5%, 10% Code

A variation to the EIA-96 standard is also used for tolerances of 2%,
5% or 10%. This variation also uses a 3 letter code. The first digit
codifies the multiplier and the last two digits codify the base value.

Multiplier

The multiplier is the same as the EIA-96 standard.
Letter Code

Multiplier

Letter Code

Multiplier

F

10

5

B

10

1

E

10

4

A

10

0

D

10

3

X or S

10

-1

C

10

2

Y or R

10

-2

Last Two Digits

2% Tolerance

5% Tolerance

10% Tolerance

Code Value Code Value Code Value Code Value Code Value
01

100

13

330

25

100

37

330

49

100

02

110

14

360

26

110

38

360

50

120

03

120

15

390

27

120

39

390

51

150

04

130

16

430

28

130

40

430

52

180

05

150

17

470

29

150

41

470

53

220

06

160

18

510

30

160

42

510

54

270

07

180

19

560

31

180

43

560

55

330

08

200

20

620

32

200

44

620

56

390

09

220

21

680

33

220

45

680

57

470

10

240

22

750

34

240

46

750

58

560

11

270

23

820

35

270

47

820

59

680

12

300

24

910

36

300

48

910

60

820

Example: A22 = 22Ω
